10.5m Bus
  • 10.5m Bus - 0 10.5m Bus - 0
  • 10.5m Bus - 1 10.5m Bus - 1

10.5m Bus

With its sleek design and spacious interior, the 10.5m Bus is the ultimate choice for your daily commute, school trips, or long-distance travel. It is equipped with state-of-the-art safety features such as seat belts and airbags for a secure and comfortable journey.

Send Inquiry

Product Description

The 10.5m Bus also boasts advanced technology, including a fully-integrated entertainment system and climate control, ensuring a comfortable journey for all passengers. Additional amenities such as onboard Wi-Fi and charging ports make this bus the perfect choice for long journeys.

Item NJL6106BEV NJL6126BEV
External dimensions(mm) (length×width×height) 10490 ×2550 × 3200   3300(Roof battery) 11990 ×2550 ×3200 , 3300(Roof  battery)
GVW(Kg) 18000 18000
Axle load 7500/11000 7500/13000
Rated passenger 92/19-38(2 steps)
92/19-37(low entrance)
95/19-46(2 steps)
95/19-45(  low entrance) 95/19-41(  low floor)
Body type Full load body
Floor type 2 steps/low entrance 2 steps/low entrance /low floor
Max. speed(km/h) 85
Max.gradability(%) 18(25  Optional)
Air conditioning(kcal) 30000 32000
Suspension type Air suspension
Tyre 275/70R22.5
HV control unit Four in 1
Motor type Permanent magnet synchronous moto
Battery capacity(kwh)(Skysource) 258/322 322/387
350/422  (CATL)
Operating mode driving mileage(km) 220~270 250~300 270~320
Charger power/charging time(Battery temperature25℃ , SOC:20%-100%) 120kw;1.8h/2.2h 2.2h/2.6h 2.4h/2.9h

Product Details
