8.5m Bus
  • 8.5m Bus - 0 8.5m Bus - 0
  • 8.5m Bus - 1 8.5m Bus - 1
  • 8.5m Bus - 2 8.5m Bus - 2

8.5m Bus

The 8.5m Bus is also equipped with advanced safety features such as anti-lock brakes, a backup camera, and an emergency brake system, which provides an added layer of safety for you and your passengers.

Send Inquiry

Product Description

What makes the 8.5m Bus unique is its size and features. With a length of 8.5m Bus, it is spacious enough to accommodate up to 39 passengers in comfortable seating. Moreover, the interior has been designed with the comfort of passengers in mind, providing amenities such as air conditioning, adjustable seats, and large windows. You can rest assured that everyone using this bus will have a comfortable and enjoyable ride.

Item NJL6856BEV NJL6896BEV
External dimensions(mm) (length×width×height) 8545 ×2500 × 3210 , 3320(Roof battery) 8995 ×2500 ×3210 ,  3320(Roof  battery)
GVW(Kg) 14500 14500
Axle load 5000/9500 5000/9500
Rated passenger 67/14-28(2 steps)
67/14-28(low entrance)
72/14-32(2 steps)
72/14-32(low entrance)
Body type Full load body
Floor type 2 steps/low entrance
Max. speed(km/h) 85
Max.gradability(%) 18(25  Optional)
Air conditioning(kcal) 24000
Suspension type Air suspension
Tyre 255/70R22.5
HV control unit Four in 1
Motor type Permanent magnet synchronous moto
Battery capacity(kwh)(Skysource) 161/193 193
Operating mode driving mileage(km) 200~250
Charger power/charging time(Battery temperature25℃ , SOC:20%-100%) 120kw;1.1h/1.3h 120kw;1.3h

Product Details
